Name: Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000
Brand: Beijing Ding Ding Future Technology Co.Ltd
SKU: Sierra 25 - 110/230-277
Price: 1 USD
Availability: InStock

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000

MOQ

1 USD

Preis

Eigenschaften Galerie Produkt-Beschreibung Fordern Sie ein Zitat

Eigenschaften

Technische Daten

Marke: CE+T

Modellnummer: Sierra 25 - 110/230-277

Produktname: Konverter/USV

Teile-Nr.: T721D50201

AC-Ausgangsspannung: 110VDC

AC-Eingangsdaten: 230 Vac / 11,8 A, 240 Vac / 11,0 A und 277 Vac / 9,5 A

Gleichstrom-Eingangsdaten: 110 Vdc (90 - 150 Vdc)

Leistungsfähigkeit: DC/AC: > 93,7 %

Leistungsfähigkeit: AC/AC: > 96 % / > 93,7 % / > 93,7 %

GW: 6 kg

Grundinformation

Herkunftsort: CN

Markenname: CET

Zertifizierung: CE UL

Modellnummer: Sierra 25 - 110/230-277

Zahlung und Versand AGB

Verpackung Informationen: Holzkartons

Lieferzeit: 6-8 Wochen

Versorgungsmaterial-Fähigkeit: 500 Sätze / Monat

Galerie

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000

Produkt-Beschreibung

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 0

CE+T Sierra 25 Bidirectional Industrial Power Converter 2.7kW–2MW Sierra 25 - 110/230-277 T724D50010

Description:

Sierra 25 – 48/230-277 can be used as a UPS to secure AC & DC loads and charge the batteries.

The 3 all bidirectional ports allow for multiple innovative applications such as grid reinjection, peak shavings,

phase balancing or energy sharing through DC distribution, among many others.

By using several modules, we can offer solutions for three-phase (3x400Vac + N) infrastructures.

The module can be integrated in small or large cabinets to reach up to 2 MW.

With our new Inview S monitoring, you can benefit from a unique experience.

The total output power per module is 2.7 kW, limited to 2.4 kW for each AC or DC port.

Key Features:

Secure AC & DC loads;
Many innovative applications;
Compatible with Inview S;
Modularity: from 2.7 kW to 2 MW;
From small to large systems.

Versions:

4 modules can be integrated into 2U high shelves to provide up to 10.8 kW (AC + DC)

Parameters:

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 2

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 3

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 4

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 10

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 11

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 14

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 15

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 16

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 17
